Galvanized Container /Gabion for Military Defence Blast Wall Flood
Erosion Control
Welded Gabion barrier with Geotextile is also named as Welded
bastion, Welded defense wall, Welded Barrier,Sand Cage, Welded
Gabion box, etc.
It is a prefabricated, multi-cellular system, made of Galvanized
welded mesh and lined with non-woven geotextile.
Units can be extended and joined using the provided joining pins.
It is easy installed with using minimal manpower and commonly
available equipment. After extended, it is filled into
sand,stone,then Welded Gabion barrier like a defence wall or
bunker,it is widely used for military fortification and flood
control.Accessories Supplied With Carrier Units.
Barrier also known as Rock basket retaining wall, flood control
barrier, etc. which is made of the steel welded mesh and lined with
non-woven geotextile, can be filled with sand, earth, cement,
stone, then as a defensive wall or bunker and widely used in the
military to protect safety.
The barrier concertainer unit is a multi-cellular wall system
manufactured from welded Zinc-Aluminum coated /hot dipped
galvanized steel wire mesh and joined with vertical,helical coil
joints.
Protecting both military and civilian personnel in dangerous
environments to ensure your workforce and your property are being
protected by the best.
Specifications
| Galvanized Container /Gabion for Military Defence Blast Wall Flood
Erosion Control |
| 0.61*0.61m,1.37*1.06m,1.37*1.22m,2.12*1.52m,2.21*2.13m |
| 3.8mm,4.0mm,4.5mm,5.0mm,etc. |
| 100x100mm,76.2*76.2mm,100*100mm |
| 200-400gr/m2 Heavy duty non-woven polypropylene, color can be beige-sand, olive green,grey,white,etc |
| |
| pre galvanized, galfan coated,hot dip galvanized |
| Wrapped with shrink film then on pallet |
Application
1.Personnel and Material Bunkers, Observation Points, Defensive
Firing Positions
2.Guard Posts, Explosives and Contraband Search Areas, Highway
Checkpoints,
3.Border Crossing Checkpoints, Protecting Existing Structures,
Flood control retaining wall
4.Coastal Erosion, Protection engineering of seaside area.
Installation
Features
1.Units can be both lined or unlined in other word it can be used together to any length, and can be stacked for
additional height.
2. The spiral hinged corners allows flat packing for ease of
transportation
3. The welded mesh frame is of highly durable construction
4. The Galfan coated welded mesh frame is ideal for containing
large amounts of the geavy fill material that
gives the system its strength.
5. The non-woven geotextile liner allowing a wide range of fill
material
Factory
Our factory established in 2006 year, and we have 14 years'
experience in research and development, we mainly do welded gabion,
weaving gabion box, welded mesh panel, steel bar grating, razor
barbed wire, chain link mesh, hexagonal wire mesh, ground staple,
T/Y post, vineyard post, and other metal products, etc....and we
enjoys high reputation at home and abroad, and we have professional
team, we have excellent workmanship and price favorable to
cooperate.
Packing
Application pictures
Cetrificate
Exhibition
Contact
FAQ
Q: Are you a manufacture or trading company?
A: We are factory, we have been in producing this product since
2006.
Q: Why choose us?
A: We have professional production line and team, Our goal is to
deliver excellence from start to finish of every project.
Q: Can you offer free sample?
A: Yes, as first cooperation usually the customer pay freight, and
we will return back this found if you make an order.
Q: Can we have your products with our own logo on package?
A: Yes, just send us your logo or printing design and the setup
cost would be quoted per artwork.
