Galvanized Welded defensive barrier with geotextile for army
The HESCO barrier or HESCO bastion is a modern gabion used for flood control and military
fortification. is made of a collapsible wire mesh container and
heavy duty fabric liner, and used as a temporary to semi-permanent
dike or barrier against blast or small-arms.
Flood barrier is made of collapsible wire mesh, geotextile, spring
wire and other fittings. It can be filled in sand, earth, cement
and stone etc, which can be obtained locally material. This new
type of gabions can be used for military fortifications, flood
barrier, and semi-permanent dike or barrier against small-arms.
Besides, it can be used in separate cell or some cells joint
together.
Flood barrier information:
Material: It is made of galvanized welded mesh, spring with other fittings,
can be filled with sand, earth, cement, stone. Can be used in
separate cell or some cells joint together.
Mesh wire :4mm-5mm
Spring wire :3mm,4mm,5mm
Mesh size:50mm×50mm,60mm×60mm,65mm×65mm,70mm×70mm,76mm×76mm,80mm×80mm.
Panel Size:0.61m×0.61m,1m×1m,1.2m×1.2m,1.5m×1.5m,1.5m×2m,2m×2m, 2.21m×2.13m or
as your request.
Finish:Electro galvanized after welded,Hot-dipped galvanized welded or
galfan coated after welded.
Geotextile: In non-woven geotextile, color can be white, beige-sand ,green color etc .
Product Item standards | Height | Width | Length | Cells |
QG MIL1 | 54''(1.37m) | 42''(1.06m) | 32'9''(10m) | 1*4+1*5 cells |
QG MIL2 | 24''(0.61m) | 24''(0.61m) | 4'(1.22m) | 2 cells |
QG MIL3 | 39''(1.00m) | 39''(1.00m) | 32'9''(10m) | 2*5 cells |
QG MIL4 | 39''(1.00m) | 60''(1.52m) | 32'9''(10m) | 2*5 cells |
QG MIL5 | 24''(0.61m) | 24''(0.61m) | 10'(3.05m) | 5 cells |
QG MIL6 | 66''(1.68m) | 24''(0.61m) | 10'(3.05m) | 5 cells |
QG MIL7 | 87''(2.21m) | 84''(2.13m) | 91'(27.74m) | 2*4+1*5 cells |
QG MIL8 | 54''(1.37m) | 48''(1.22m) | 32'9''(9.14m) | 1*4+1*5 cells |
QG MIL9 | 39'(1.00m) | 30''(0.76m) | 30'(9.14m) | 2*6 cells |
QG MIL10 | 87''(2.21m) | 60''(1.52m) | 100'(30.5m) | 4*5 cells |
QG MIL11 | 48''(1.22m) | 12''(0.3m) | 4'(1.22m) | 4 cells |
QG MIL12 | 84''(2.13m) | 42''(1.06m) | 108'(33m) | 6*5 cells |
QG MIL19 | 108''(2.74m) | 42''(1.06m) | 10'5''(3.18m) | 3 cells |
Application:
∗Perimeter Security and Defence Walls,
∗Equipment Revetments,
∗ garden landscaping decorative
∗Personnel and Material Bunkers, Observation Points, Defensive Firing Positions
∗Guard Posts, Explosives and Contraband Search Areas, Highway Checkpoints,
∗Border Crossing Checkpoints, Protecting Existing Structures, Flood control retaining wall
∗Coastal Erosion, Protection engineering of seaside area.
