Mil 10 Military Edge Protection Wall Sand gabion fortress and
welded gabion blockhouse
Wire diameter: 4mm, 5mm
Mesh size: 50mmx50mm, 76.2mmx76.2mm,100mmx100mm
Panel size: 2.21mx2.13m, 1.37mx1.06m, 0.61mx0.61m, it also can be
customized according to customers requirement
Geotextile: in heavy duty non-woven polypropylene
Finish: hot dipped galvanized, galfan coated
Packing: packed in pallet then wrapped with shrink film
It is also named as defensive barrier,
barrier explosion-proof wall, hesco bastion, flood barrier,
blast wall, military bunker, hesco bag, multi-cellular defense
barrier system, military barricades, military sand wall, etc.
Product feature:
1.Units can be both lined or unlined in other word it can be used together to any length, and can be stacked for
additional height.
2. The spiral hinged corners allows flat packing for ease of
transportation
3. The welded mesh frame is of highly durable construction
4. The Galfan coated welded mesh frame is ideal for containing
large amounts of the geavy fill material that
gives the system its strength.
5. The non-woven geotextile liner allowing a wide range of fill
material
Product installation:
1).Unpack the collapsible wire mesh container from package.
2).Unfold the barrier and connect barriers to reach the designed
length
3).Fill soil, sand or gravel into the container. The common machine
is front end loader.
4).Compact the content
5).Add layers if required.
Product Item standards | Height | Width | Length | Cells |
QG MIL1 | 54''(1.37m) | 42''(1.06m) | 32'9''(10m) | 1*4+1*5 cells |
QG MIL2 | 24''(0.61m) | 24''(0.61m) | 4'(1.22m) | 2 cells |
QG MIL3 | 39''(1.00m) | 39''(1.00m) | 32'9''(10m) | 2*5 cells |
QG MIL4 | 39''(1.00m) | 60''(1.52m) | 32'9''(10m) | 2*5 cells |
QG MIL5 | 24''(0.61m) | 24''(0.61m) | 10'(3.05m) | 5 cells |
QG MIL6 | 66''(1.68m) | 24''(0.61m) | 10'(3.05m) | 5 cells |
QG MIL7 | 87''(2.21m) | 84''(2.13m) | 91'(27.74m) | 2*4+1*5 cells |
QG MIL8 | 54''(1.37m) | 48''(1.22m) | 32'9''(9.14m) | 1*4+1*5 cells |
QG MIL9 | 39'(1.00m) | 30''(0.76m) | 30'(9.14m) | 2*6 cells |
QG MIL10 | 87''(2.21m) | 60''(1.52m) | 100'(30.5m) | 4*5 cells |
QG MIL11 | 48''(1.22m) | 12''(0.3m) | 4'(1.22m) | 4 cells |
QG MIL12 | 84''(2.13m) | 42''(1.06m) | 108'(33m) | 6*5 cells |
QG MIL19 | 108''(2.74m) | 42''(1.06m) | 10'5''(3.18m) | 3 cells |
