Hot dipped galvanized Razor Wire Prison Fence Stop Inmates Escaping
and Intruders Entering
Razor Barbed Wire is also named concertina coils or razor type
barbed wire. It is a kind of modern security fencing materials with
better protection and fencing strength made of hot-dipped
galvanized steel sheets or stainless steel sheets.
- Material: Hot Dipped Galvanized sheet Hot Dipped Galvanized Wire
- Core Wire Diameter: 2.7±0.1mm
- Razor Barbed sheet thickness: 0.5±0.05mm
- Razor Loop Diameter: 300mm, 400mm, 450mm, 500mm, 600mm, 700mm, 800mm, 900mm, 1000mm. 450mm(3 clips), 500mm(3 clips), 900mm(5 clips) are the usually
sizes
- Razor Barbed Wire per coil weight: Be produced as customers requirements.
- Meters of per coil Razor Barbed Wire: the greater the stretch strength, the greater the distance between
them.
Assortment:
Razor wire concertina
The razor sharp barbed hooks of the razor wire and the small
distances between the blades provide an effective protection.
The razor barded wire is both a formidable physical barrier and an
excellent psychological deterrent. So it protects from the vandals
to vulnerable sites, which like jail, military , airdrome, high
security border barrier.
Barbed tape wire
The barbed tapes are able to be fitted to walls, fences or eaves
without the need for heavy duty straining post, supports or
cautionary wires.
Razor Wire Size Specifications |
Peference Model | Thickness (mm) | Wire Diameter (mm) | Barb Length
(mm) | Bard Width
(mm) | Bard Spacing
(mm) |
BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
BTO-15 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
BTO-22 | 0.5±0.05 | 2.5±0.1 | 02±1 | 15±1 | 34±1 |
BTO-28 | 0.5±0.05 | 2.5±0.1 | 28 | 15 | 45±1 |
CBT-30 | 0.5±0.05 | 2.5±0.1 | 30 | 18 | 45±1 |
CBT-60 | 0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±1 |
CBT-65 | 0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±1 |
Outside Diameter | No. of Loops | Standard Length per Coil | Razor Type | Notes |
450mm | 33 | 7M-8M | CBT-60, 65 | Single Coil |
500mm | 56 | 12M-13M | CBT-60, 65 | Single Coil |
700mm | 56 | 13M-14M | CBT-60, 65 | Single Coil |
960mm | 56 | 14M-15M | CBT-60, 65 | Single Coil |
450mm | 56 | 8M-9M (3clips) | BTO-10, 12, 18, 22, 28, 30 | Cross Type |
500mm | 56 | 9M-10M (3clips) | BTO-10, 12, 18, 22, 28, 30 | Cross Type |
600mm | 56 | 10M-11M (3clips) | BTO-10, 12, 18, 22, 28, 30 | Cross Type |
600mm | 56 | 8M-10M (5clips) | BTO-10, 12, 18, 22, 28, 30 | Cross Type |
700mm | 56 | 10M-12M (5clips) | BTO-10, 12, 18, 22, 28, 30 | Cross Type |
800mm | 56 | 11M-13M (5clips) | BTO-10, 12, 18, 22, 28, 30 | Cross Type |
900mm | 56 | 12M-14M (5clips) | BTO-10, 12, 18, 22, 28, 30 | Cross Type |
960mm | 56 | 13M-15M (5clips) | BTO-10, 12, 18, 22, 28, 30 | Cross Type |
980mm | 56 | 14M-16M (5clips) | BTO-10, 12, 18, 22, 28, 30 | Cross Type |
Hot dipped galvanized Razor Wire Prison Fence Stop Inmates Escaping
and Intruders Entering Application:
Razor wire tape is widely used in gardens, hospitals, industrial
and mining enterprises, prisons, border posts, detention centers,
government building or other security facilities.
Also used for division of railway, highway, agricultural fencing,
etc.
Certification
