Architecture 5mm Galfan Welded Mesh Gabion

    Buy cheap Architecture 5mm Galfan Welded Mesh Gabion from wholesalers

    Buy cheap Architecture 5mm Galfan Welded Mesh Gabion from wholesalers
    • Buy cheap Architecture 5mm Galfan Welded Mesh Gabion from wholesalers

    Architecture 5mm Galfan Welded Mesh Gabion

    Ask Lasest Price
    Brand Name : KAAP
    Model Number : KP20200107
    Certification : ISO9001 SGS
    Price : $6-15/PCS
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : about 5000pcs per week
    Delivery Time : within 7-10 days
    • Product Details
    • Company Profile

    Architecture 5mm Galfan Welded Mesh Gabion

    Gabion Wall Architectural Gabion Wall Welded mesh For Argentina


    About Gabion Wall


    In front of the façades, we placed gabions, a device used in river engineering, that is, wire containers filled with stones. Added to the walls, they form an inert mass that insulates the rooms against heat by day and cold at night.


    The gabions are filled more or less densely as needed so that parts of the walls are very impenetrable while others allow the passage of light: natural light comes into the rooms during the day and artificial light seeps through the stones at night. You could describe our use of the gabions as kind of stone wickerwork with varying degrees of transparency, more like skin than like traditional masonry.



    Specifications

    Size
    1.0x0.3x0.3 m
    Wire diameter
    3.8 mm
    Opening mesh
    5x10 cm
    Surface treatment
    galvanized

    Manufacturer certified according toISO 9001
    MaterialHighly elastic steel wire
    Coating95% zinc 5% aluminium
    Material thickness:4.5 mm
    tensile strength> 450 N / mm²
    Mesh width100/100 mm, 100/50 mm


    Applications
    • Mass gravity retaining walls
    • Facing units to reinforced soil walls
    • Landfill
    • Perimeter walling
    • Acoustic barriers
    • River and coastal protection
    • Reed beds
    • Abutments
    • Landscaping
    • Free standing walls
    • Temporary works
    Features
    1.Anti-erosion
    2.Weather resistant
    3.High tensile strength
    4.Easily assembled
    Packing
    Company profile
    Our factory established in 2006 year, and we have 14 years' experience in research and development, we mainly do welded gabion, weaving gabion box, welded mesh panel, steel bar grating, razor barbed wire, bird spike,chain link mesh, hexagonal wire mesh, ground staple, T/Y post, vineyard post, and other metal products, etc....and we enjoys high reputation at home and abroad, and we have professional team, we have excellent workmanship and price favorable to cooperate.
